Explore our export-grade industrial racking and material handling equipment manufactured for demanding logistics environments across Thailand and Southeast Asia.
Pallet flow racking—also recognized as gravity flow or dynamic flow racking—represents the pinnacle of high-density, First-In, First-Out (FIFO) pallet storage engineering. Designed for operations demanding flawless stock rotation, elevated throughput, and reduced forklift travel times, pallet flow systems replace conventional aisles with inclined roller tracks.
Unlike standard static selective racking that requires dedicated aisles between every row, a pallet flow rack system uses dedicated loading aisles on the entry side and picking aisles on the discharge side. Pallets are placed at the high end of an inclined wheel or roller track (typically pitched at a precise 3.5% to 4.5% gradient) and glide smoothly downward under controlled gravity toward the pick face.
When a pallet is retrieved from the picking face, the trailing pallets automatically slide forward into position. This mechanical logic maximizes storage density by eliminating up to 75% of forklift travel aisles while establishing absolute FIFO inventory enforcement—a vital operational necessity for food processing plants, cold chain storage facilities, and pharmaceutical logistics operators across Thailand.
Our engineered pallet flow tracks incorporate heavy-duty steel rollers, custom speed controllers (centrifugal brake rollers), and safety pallet separators. This ensures that heavy pallets (up to 1,500 kg) maintain a safe, controlled speed of less than 0.3 m/s down the lane regardless of ambient temperature or pallet bottom quality.
Direct-drive centrifugal brake rollers dynamically regulate pallet momentum down the lane, preventing runaway speeds and impact damage at the picking face.
Mechanical lock separators isolate the lead pallet from line pressure of rear pallets, enabling frictionless forklift extraction without binding or back-pressure.
Thailand’s position as Southeast Asia's logistics hub has driven rapid expansion across the Eastern Economic Corridor (EEC) and major industrial hubs. Our pallet flow systems are customized to match local warehouse structural parameters, tropical climate conditions, and specific industry demands.
Thailand’s "Detroit of Asia" demands high-density, error-free component staging. Our heavy-duty pallet flow racks store engine blocks, body panels, and high-velocity automotive sub-assemblies directly adjacent to assembly lines in Rayong and Chonburi industrial parks, ensuring zero line-stoppage and strict FIFO batch control.
Operating in harsh refrigerated environment down to -28°C, cold-storage real estate in Thailand carries premium operational costs. Structural steel pallet flow systems double storage capacity within existing freezer footprints while hot-dip galvanized finishes prevent rust caused by tropical humidity condensation during dock door cycles.
Serving urban retail networks across Bangkok Metropolitan Region, consumer goods distributors deploy multi-tier pallet flow pick modules. Fast-moving SKUs flow seamlessly to lower-level case-picking tunnels, accelerating order dispatch times and reducing labor costs across high-bay distribution centers.
Comparing high-density warehouse storage options to help Thai logistics managers select the ideal racking architecture based on SKU diversity, rotation logic, and equipment compatibility.
| Storage System Type | Inventory Rotation | Storage Density | Forklift Aisle Demand | Risk of Rack Impact | Ideal Thailand Sector |
|---|---|---|---|---|---|
| Pallet Flow Racking | 100% FIFO | Very High (85%+) | Low (2 Aisles Only) | Minimal (External Only) | Food & Beverage, Pharma, Cold Storage |
| Pushback Racking | LIFO | High (70-75%) | Medium (1 Aisle Access) | Low (Cart Protected) | Chemicals, General Wholesale, Automotive |
| Drive-In Racking | LIFO | Very High (75-80%) | Very Low | High (Forklift Enters Rack) | Raw Materials, Bulk Single-SKU Staging |
| Selective Pallet Rack | 100% Random Access | Standard (40-50%) | High (Aisle Every Row) | Medium (High Forklift Traffic) | 3PL Multi-Tenant Warehouses, Spare Parts |
Thailand's industrial sector is undergoing a profound structural evolution driven by Thailand 4.0 initiatives, rapid industrial automation, and regional supply chain realignments. Warehouse space planning in 2026 demands future-ready infrastructure capable of supporting dynamic automation.
We combine precision structural manufacturing with deep knowledge of Thailand's unique climatic and seismic requirements. From engineering calculations compliant with international standards to smooth customs clearance at Laem Chabang port, we deliver turnkey reliability.
✓ Steel structural grades Q235B & Q355B
✓ Seismic structural bracing options for Northern Thailand
✓ Custom roller lane configurations for Thai standard plastic/wooden pallets
FlexBeam Warehouse Equipment Co., Ltd. delivers engineered industrial structural rack systems built to rigorous global technical standards, giving importers and logistics operators total structural confidence.
Our upright frames and structural channel beams undergo full scale physical load testing and finite element analysis (FEA) to ensure zero deflection under peak static and dynamic load scenarios.
Featuring advanced electrostatic powder coating (60-80 micron thickness) and hot-dip galvanizing options specifically formulated to resist tropical humidity and coastal atmospheric salt exposure in Southern Thailand.
Direct export shipping from factory port to Laem Chabang or Bangkok Port. Every container is systematically bundled, color-coded, and shipped with clear installation assembly documentation.
Addressing key engineering, environmental, and commercial inquiries when procuring pallet flow racking systems for Thai facilities.
Thailand’s high relative humidity can cause surface rust on non-treated steel rollers, leading to increased friction and stuck pallets. FlexBeam solves this by providing zinc-galvanized or stainless steel rollers fitted with sealed precision bearings. Additionally, our frame structures feature electrostatic powder coating or hot-dip galvanizing, ensuring smooth flow performance even in non-air-conditioned warehouses across Chonburi and Rayong.
Our flow lanes can be engineered for standard Thai wooden pallets (such as 1000mm x 1200mm or 1100mm x 1100mm industrial plastic pallets). The critical factor is bottom runner consistency. Wooden pallets with broken bottom boards or bowed plastic pallets can unevenly distribute weight. We customize roller spacing (full-width vs. multi-track rollers) and pitch angle based on your exact pallet physical specifications.
Yes. Pallet flow racking is one of the most effective solutions for cold storage rooms operating down to -28°C. By eliminating forklift inner aisles, freezer volume utilization increases by up to 85%. Our cold-room flow systems utilize specialized synthetic lubricants inside sealed bearings and low-temperature structural steel that retains impact toughness without becoming brittle.
To provide an engineered CAD layout and quotation, we require: (1) Pallet footprint dimensions and maximum load weight; (2) Available clear building height; (3) Number of SKUs and target pallet capacity; (4) Floor slab specifications and concrete thickness; (5) Forklift model and maximum mast lift height; (6) Facility ambient operating temperature profile.
All FlexBeam storage racks are engineered in reference to globally accepted structural codes including ANSI MH16.1 (RMI specification), EN 15512 (European racking standard), and AS 4084 (Australian steel storage racking code). Every rack layout is calculated for structural safety margins, seismic loading factors, and point-load resistance on warehouse slab floors.
Because forklifts operate only at the front and back entry/exit faces, the internal flow lanes remain completely isolated from vehicle collision. To protect the vulnerable front upright columns, we supply heavy-duty structural column protectors, floor-anchored rub rails, and entry guide angles that funnel pallets safely onto the roller track without damaging side beams.
Consult with our structural warehouse engineers to receive a complimentary CAD floor plan layout, storage capacity optimization assessment, and direct factory pricing for your Thailand facility.
